WebGL gradient shaders, explained for designers

A WebGL gradient is a gradient that your browser paints with a shader: a short program that runs on the graphics chip (the GPU) and answers one question for every pixel on screen, "what colour are you right now?" A CSS gradient is a fixed recipe of colours and positions. A shader is a formula, so it can bend, grain, glow and move the colour, and do it again sixty times a second, without any image being downloaded.

You don't need to write shaders to design with them, but knowing what they can and can't do helps you brief a developer, judge a tool and decide when a plain CSS gradient is the better choice.

What a shader is, in plain words

WebGL is the browser's way of talking to the GPU, and every WebGL drawing uses two kinds of shader. The vertex shader places shapes; for a full-screen gradient that is just one rectangle covering the canvas. The fragment shader does the interesting work: it runs once per pixel, receives that pixel's position and the current time, and returns a colour.

Because the GPU runs thousands of these tiny programs in parallel, a formula that would be slow in ordinary code becomes cheap enough to redraw every frame. Here is a complete fragment shader for a three-colour gradient whose boundary sways gently over time, with a line of grain on top.

#version 300 es
precision highp float;

uniform vec2 u_resolution;   // canvas size in pixels
uniform float u_time;        // seconds since start
out vec4 outColor;

void main() {
  vec2 uv = gl_FragCoord.xy / u_resolution;   // 0 to 1 across the canvas

  vec3 night  = vec3(0.07, 0.04, 0.18);  // #120a2e
  vec3 violet = vec3(0.49, 0.23, 0.93);  // #7c3aed
  vec3 coral  = vec3(0.98, 0.45, 0.45);  // #fa7373

  // A slow wave bends the blend so the colours drift.
  float wave = sin(u_time * 0.3 + uv.x * 3.0) * 0.08;
  float t = clamp(uv.y + wave, 0.0, 1.0);

  vec3 color = mix(night, violet, smoothstep(0.0, 0.6, t));
  color = mix(color, coral, smoothstep(0.55, 1.0, t));

  // Fine grain: a different random value per pixel, per frame.
  float n = fract(sin(dot(gl_FragCoord.xy + u_time, vec2(12.9898, 78.233))) * 43758.5453);
  color += (n - 0.5) * 0.04;

  outColor = vec4(color, 1.0);
}

How a shader gradient differs from a CSS gradient

A CSS gradient is declarative: you list colours and positions, and the browser paints them. It is the right tool most of the time. A shader is procedural: you describe how colour should behave, and the maths produces it. That difference shows up in what each can do and what each costs.

Why shader gradients feel alive

Three techniques do most of the work, and you will hear developers name them. Noise is smooth randomness: instead of a straight blend, the colour follows a landscape of soft hills, which is why shader gradients look organic rather than geometric. Domain warping feeds noise back into itself, so the colour folds and swirls like ink in water. Time slides the whole landscape along, which turns a still field into a drift.

• Grain can be generated per pixel and per frame, so it shimmers like film instead of sitting still like a texture laid on top. See grainy gradients.
• Light can be faked with a few lines: a highlight that follows the noise reads as sheen on silk or glass.
• Resolution is free. The formula runs at whatever size the screen is, so a shader gradient stays crisp on a phone and on a 4K monitor with the same code.
• Banding is easier to beat, because the shader can add a little dither before the colour is rounded to 8 bits. Gradient banding explains why that matters.

The cost of a moving WebGL background

A shader that animates keeps the GPU working for as long as it is on screen. On a desktop that is barely noticeable. On an older phone it can mean warm hands, a draining battery and a page that scrolls less smoothly. The costs scale with the number of pixels and the complexity of the formula, so a full-screen shader on a high-density display is the heaviest case. Do gradients slow a website down covers how to measure it.

1. 1

   Show the CSS fallback first

   Paint the still gradient immediately, then fade the canvas in once the shader has drawn its first frame. Nobody should see an empty box.

2. 2

   Check that WebGL is available

   Some browsers, devices and privacy settings turn it off. If the context can't be created, keep the fallback.

3. 3

   Respect reduced motion

   If the visitor asks for less motion, draw one frame and stop. Reduced motion explains the setting.

4. 4

   Pause when it can't be seen

   Stop the animation loop when the canvas scrolls out of view or the tab is hidden.

5. 5

   Render at a sensible resolution

   Soft gradients rarely need every device pixel. Drawing at half resolution and letting the browser scale up can cut the work a lot for a blur you can't tell apart.

const canvas = document.querySelector('#hero-canvas')
const gl = canvas.getContext('webgl2')
const still = matchMedia('(prefers-reduced-motion: reduce)').matches
let visible = true

if (!gl) {
  canvas.remove() // the CSS gradient behind it stays
} else {
  new IntersectionObserver(([entry]) => {
    visible = entry.isIntersecting
  }).observe(canvas)

  const frame = (ms) => {
    if (visible && !document.hidden) draw(gl, ms / 1000) // your draw call
    if (!still) requestAnimationFrame(frame)
  }
  requestAnimationFrame(frame)
}

For reference, the WebGL API on MDN documents every call used here, and caniuse tracks WebGL2 support across browsers.

Designing a shader gradient: what to brief

You can direct a shader without reading GLSL. Brief it the way you would brief a material, not a colour swatch. Give the ground colour and the three to five colours that live on it, in hex. Describe the structure: soft pools, long bands, folded silk. Name the speed in seconds per cycle rather than "slow", because slow means different things to different people. Say how much grain, and whether it moves. Finally, say where text will sit, so the busiest part of the field stays away from it.

How Gradiently draws Marks with shaders

Gradiently's Marks are shader gradients. Each Mark is a recipe of colours, up to three stacked materials, light, grain and motion, and the Studio draws it live with WebGL2 behind whatever you design. Because it is computed rather than stored, the same Mark renders sharply at any of the platform sizes and moves when you export a looping video. The renderer also knows where your words are, so it can move the calmest part of the field behind them. What is a Mark explains the recipe in full.
